ANBO Manufacturing 30 HP Tractor Grapple Rake
• Manufactured in Colville, WA
• AR400F Steel Frame
• Optimized for Small Tractors
Built for 30 HP and under tractors, the ANBO Manufacturing GR30 Grapple Rake delivers premium strength and versatility in a compact frame. Its AR400F steel build, greaseable pivots, and clamshell design make it ideal for brush, rock, and debris removal. Made in the USA with long-lasting reliability and warranty protection.
About the Product
Product Features
The ANBO GR30 Grapple Rake is purpose-built for compact tractors up to 30 HP, offering professional-grade performance in a smaller, efficient design. Its clamshell-style rake makes clearing, digging, and loading debris easy, while maintaining superior control. Crafted from American made AR400F steel, this grapple combines lightweight agility with serious strength. Greaseable pivot points, and protected hose routing, ensure lasting reliability. Ideal for brush clearing, rock removal, and landscaping cleanup, the GR30 is proudly made in the USA.
- Designed for tractors up to 30 horsepower.
- Clamshell grapple for efficient raking, digging, and moving.
- Built from 1/4″ AR400F steel.
- 2″ x 6″ hydraulic cylinders for reliable clamping power.
- All pivot points greaseable; hoses securely routed for protection.
- Proudly made in the USA with a 2-year grapple and 3-year cylinder warranty.
Product Specs
Model
ANBO-GR30-6-32
ANBO-GR30-6-38
ANBO-GR30-6-44
ANBO-GR30-6-50
ANBO-GR30-6-57
ANBO-GR30-6-63
ANBO-GR30-6-69
Width
32"
38"
44"
50"
57"
63"
69"
Max HP
30 HP
30 HP
30 HP
30 HP
30 HP
30 HP
30 HP
Tine Spacing
6"
6"
6"
6"
6"
6"
6"
Tine Size
1/4" AR400F Steel
1/4" AR400F Steel
1/4" AR400F Steel
1/4" AR400F Steel
1/4" AR400F Steel
1/4" AR400F Steel
1/4" AR400F Steel
Opening
36"
36"
36"
36"
36"
36"
36"
Cylinder Size
2" x 6"
2" x 6"
2" x 6"
2" x 6"
2" x 6"
2" x 6"
2" x 6"
ANBO Manufacturing
ANBO Manufacturing is known for building some of the toughest, if not the grapples in the industry. American-made, precision engineered, and built from premium AR400F steel for unmatched strength, wear resistance, and lifetime durability. Their grapples are trusted and known by farmers, land managers, contractors, and heavy equipment operators across the country for one simple reason: they hold up when nothing else does.
After briefly closing in 2018, ANBO was brought back to life in 2020 by a former customer who believed equipment this well-built shouldn’t disappear. Still family owned and proudly built in the Colville, WA, ANBO is focused on doing what they do best: crafting high-quality attachments that outlast the machines they’re mounted on.
